TDS1000 and TDS2000 Series Digital Storage Oscilloscopes Service Manual
7-- 1
Diagrams
This section describes the electrical operation of the TDS1000- and TDS2000-
series oscilloscopes using the major circuit blocks or modules. Figure 7--1 shows
the oscilloscope module interconnections.
The shaded area in Figure 7--1 represents modules and circuits used only in
four-channel oscilloscopes.
