Maintenance

TDS1000 and TDS2000 Series Digital Storage Oscilloscopes Service Manual

6-- 11

4. Remove the four screws located on the rear case. Tilt the handle to gain

better access to the top two screws.

5. Lift the rear case off of the oscilloscope.

Rear case

Remove rear case

screws (4)

ESD Grounding ears

Figure 6--4: Removing and installing the rear case
