Maintenance
TDS1000 and TDS2000 Series Digital Storage Oscilloscopes Service Manual
6-- 13
ESD grounding ears are properly
aligned with the rear case slots when
they are visible in approximately one
half the width of the slots.
Rear case
slots (4)
ESD grounding ears (4)
Main board notches
Figure 6--5: Aligning the oscilloscope rear case
