TDS2CMA Communications Module
138
TDS1000/2000-Series Digital Oscilloscope User Manual
CH 1
PROBE COMP
6. On the oscilloscope, push UTILITY " Options " RS-232.
7. Check that the menu settings match those listed in the table on
page 137.
8. From your PC terminal program, type ID?, then press the Re turn
or Enter key to send the command. The oscilloscope sends back
its identification string, which should look similar to the
following:
ID TEK/TDS 1002,CF:91.1CT,FV:V1.09 TDS2CMA:CMV:V1.04
If you do not get a ny response, refer to the troubleshooting ste ps
that start on page 139.
9. Send the command FACtory to reset the oscilloscope to factory
settings (defaults).
