Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
153
Oscilloscope Specifications (Cont.)
Inputs
Channel-to-Channel
Common Mode
R
j
i
i
l
TDS1002 and
TDS2002
TDS1012, TDS2012, TDS2014, TDS2022
and TDS2024
Rejection, typical
100:1 at 60 Hz
20:1at30MHz*
100:1 at 60 Hz
20:1at50MHz*
Measured on MATH Ch1 -- Ch2 waveform, with test signal
applied between signal and common of both channels, and with
the same VOLTS/DIV and coupling settings on each channel
Measured on MATH Ch3 -- Ch4 waveform for 4-channel models
Channel-to-Channel
Crosstalk
TDS1002 and
TDS2002
TDS1012,
TDS2012 and
TDS2014
TDS2022 and
TDS2024
≥ 100:1 at
30 MHz*
≥ 100:1 at 50 MHz* ≥ 100:1 at
100 MHz*
Measured on one channel, with test signal applied between
signal and common of the other channel, and with the same
VOLTS/DIV and coupling settings on each channel
Vertical
Digitizers 8-bit resolution (except when set to 2 mV/div), each channel
sampled simultaneously
VOLTS/DIV Range 2 mV/div to 5 V/div at input BNC
Position Range 2 mV/div to 200 mV/div, ±2V
> 200 mV/div to 5 V/div, ±50 V
* Bandwidth reduced to 6 MHz with a 1X probe.
