TDS1000/2000-Series Digital Oscilloscope User Manual
Oscilloscope Specifications (Cont.)
Horizontal
Sample Rate Range TDS1002, TDS1012,
TDS2002, TDS2012 and
TDS2014
TDS2022 and TDS2024
5S/sto1GS/s 5S/sto2GS/s
Waveform Interpolation (sin x)/x
Record Length 2500 samples for each channel
SEC/DIV Range TDS1002, TDS1012,
TDS2002, TDS2012 and
TDS2014
TDS2022 and TDS2024
5ns/divto50s/div,ina1,2.5,
5 sequence
2.5ns/divto50s/div,ina1,
2.5, 5 sequence
Sample Rate and
Delay Time Accuracy
±50 ppm over any ≥1 ms time interval
Delta Time Measure-
A
(
F
l
l
Conditions Accuracy
ment Accuracy (Full
Bandwidth)
Single-shot, Sample mode
±(1 sample interval + 100 ppm
× reading + 0.6 ns)
> 16 averages ±(1 sample interval + 100 ppm
× reading + 0.4 ns)
Sample interval = s/div ÷ 250
Position Range TDS1002, TDS1012, TDS2002, TDS2012 and TDS2014
g
5ns/divto10ns/div (--4 div × s/div) to 20 ms
25 ns/div to 100 s/div
(--4 div × s/div) to 50 ms
250 s/divto50s/div
(--4 div × s/div) to 50 s
TDS2022 and TDS2024
2.5 ns/div to 5 ns/div (--4 div × s/div) to 20 ms
