TDS1000B and TDS2000B Series Oscilloscope Service Manual
Table 1- 1: Oscilloscope specifications (Cont.)
Inputs
Input Coupling DC, AC, or GND
Input Impedance, DC
Coupled
1MΩ ±2% in parallel with 20 pF ±3pF
P2220 Probe
Attenuation
1X, 10X
Supported Probe
Attenuation Factors
1X, 10X, 20X, 50X, 100X, 500X, 1000X
Supported Current
Probe Scales
5 V/A, 1 V/A, 500 mV/A, 200 mV/A, 100 mV/A, 20 mV/A, 10 mV/A, 1 mV/A
Maximum Voltage Overvoltage Category* Maximum Voltage
Between Signal and
CAT I and CAT II 300 V
RMS
e
eren
e
npu
BNC
Derate at 20 dB/decade above 100 kHz to 13 V peak AC at 3 MHz
{
and above.
For non-sinusoidal waveforms, peak value must be less than 450 V. Excursion above 300 V should be less
than 100 ms duration and the duty factor is limited to ≤ 44%.
RMS signal level includi ng any DC component removed through AC coupling must be limited to 300 V.
t
ese
ues
re e
ee
e
,
m
ge to t
eos
os
ope m
resu
t.
Channel-to-Channel
Common Mode
TDS1001B TDS1002B, TDS2002B,
TDS2004B
TDS1012B, TDS2012B, TDS2014B, TDS2022B,
TDS2024B
Rejection, typical
100:1 at 60 Hz
20:1at20MHz
{
100:1 at 60 Hz
20:1at30MHz
{
100:1 at 60 Hz
10:1at50MHz
{
Measured on MATH Ch1 -- Ch2 waveform, with test signal applied between signal and common of both
channels, and with the same VOLTS/DIV and coupling settings on each channel
Measured on MATH Ch3 -- Ch4 waveform for 4-channel models
Channel-to-Channel
Crosstalk
TDS1001B TDS1002B, TDS2002B,
TDS2004B
TDS1012B, TDS2012B,
TDS2014B
TDS2022B, TDS2024B
≥ 100:1 at 20 MHz
{
≥ 100:1 at 30 MHz
{
≥ 100:1 at 50 MHz
{
≥ 100:1 at 100 MHz
{
Measured on one channel, with test signal applied between signal and common of the other channel, and
with the same VOLTS/DIV and coupling settings on each channel
*
Refer to the Overvoltage Category description in the TDS1000B and TDS2000b User manual, available on the Tektronix Web site
at www.tektronix.com/manuals.
{
Bandwidth reduced to 6 MHz with a 1X probe.
