Tektronix TDS3032

Operating Information
2–18
TDS3000 Series Service Manual
Front-Panel Connectors
[ 5V Ɩ
1
2
CH 4CH 3
CH 2CH 1
1M W , 13pF ≤300 VRMS CATl
PROBE COMP
3
PROBE COMP
[ 5V Ɩ
2
1
EXT TRIG
50 W
≤5VRMS
50 W
≤5VRMS
1M W , 13pF ≤300 VRMS CATl
1M W , 13pF ≤300 VRMS CATl
CH 2CH 1
50 W
≤5VRMS
1M W , 17pF ≤300 VRMS CATl
1. PROBE COMP. Square wave signal source to compensate probes.
2. CH1, CH 2, (CH3, CH4). Channel inputs with TekProbe interface.
3. EXT TRIG. External trigger input with TekProbe interface (two-channel models only).
