TDS3000 Series Service Manual
4–1
Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the
n
symbol. The following equipment, or a suitable equivalent,
is required to complete these procedures.
Description
Minimum
requirements
Examples
DC Voltage Source 3 mV to 4 V, ±0.1% accuracy
Wavetek 9500
Oscilloscope Calibrator with
Leveled Sine Wave Generator 50 kHz to 500 MHz, ±3%
amplitude accuracy
Oscilloscope Calibrator with
two 9510 Output Modules
Time Mark Generator 10 ms period, ±50 ppm accu-
racy
You may need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all TDS3000 oscilloscope models. Please disregard
checks that do not apply to the specific model you are testing.
Photocopy the test record on the next two pages and use them to record the
performance test results for your oscilloscope.
