Tektronix TDS3032 Service Manual

Performance Verification
TDS3000 Series Service Manual
4–3
Performance checks High limitTest resultLow limit
Channel 3 DC
measurement
1 mV/div 99.25 mV 100.8 mV
measurement
accuracy
2 mV/div
–7.540 mV –6.460 mV
accuracy
5 mV/div –101.8 mV –98.24 mV
50 mV/div 982.4 mV 1.018 V
50 mV/div 632.4 mV 667.6 mV
50 mV delta 340.5 mV 359.5 mV
90 mV/div –339.3 mV –290.7 mV
200 mV/div 9.900 V 10.10 V
1 V/div –10.30 V –9.698 V
Channel 4 DC
measurement
1 mV/div 99.25 mV 100.8 mV
measurement
accuracy
2 mV/div
–7.540 mV –6.460 mV
accuracy
5 mV/div –101.8 mV –98.24 mV
50 mV/div 982.4 mV 1.018 V
50 mV/div 632.4 mV 667.6 mV
50 mV delta 340.5 mV 359.5 mV
90 mV/div –339.3 mV –290.7 mV
200 mV/div 9.900 V 10.10 V
1 V/div –10.30 V –9.698 V
Channel 1 bandwidth 425 mV —
Channel 2 bandwidth 425 mV —
Channel 3 bandwidth 425 mV —
Channel 4 bandwidth 425 mV —
Channel 1
trigger sensitivity
rising slope stable trigger —
trigger sensitivity
falling slope stable trigger —
Channel 2
trigger sensitivity
rising slope stable trigger —
trigger sensitivity
falling slope stable trigger —
Channel 3
trigger sensitivity
rising slope stable trigger —
trigger sensitivity
falling slope stable trigger —
Channel 4
trigger sensitivity
rising slope stable trigger —
trigger sensitivity
falling slope stable trigger —
Sample rate and delay time accuracy –2 divisions +2 divisions
