Appendix B: Factory Setup
Control Changed b y factory setup to
Saved setups
No change
Trigger holdoff
250.8 ns
Trigger mode Auto
Trigger type Edge
Utility language No change
Utility date /time display On
Utility I/O
No change
Utility hard copy No change
Vertical bandwidth Full
Vertical coupling
DC 1 MΩ
Vertical inv
ert
Off
Vertical offset
0V
Vertical position 0 div
Vertical probe setup
Voltage, 1 X (unless a non-1 X probe
is attached)
Vertical volts/div 100 mV/div
Vi
deo trigger standard
525/NTSC
Video trigger on All lines
Waveform file format
No change
XY display
Off
TDS3000C Series O scilloscope User Manual 163
