Removal and Installation Procedures
6-- 16
TDS7104 & TDS7054 Service Manual
All left and right cover
mounting holes are
indicated as shown.
Left side cover
Right side cover
T-15 T orx
screw (11)
Figure 6--5: Cover removal
