Tektronix TDS7054

Removal and Installation Procedures
TDS7104 & TDS7054 Service Manual
6-- 27
Back view
J7
J4
J6
J1
Display module
Display
adaptor board
T--15 Torx
screw (3)
J5
Inverter board
Figure 6--14: Display adaptor board removal
Clip to secure
connector as shown
Slide the clip
over connector
J11
J10
Figure 6--15: Cable clip removal
