Tektronix TDS7054

Specifications
1-8
TDS7104 & TDS7054 Service Manual
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
DC gain accuracy, ±1% in Sam ple or Average acquisition mode
DC vol tage measurement accuracy Measurement type DC accuracy (in volts)
Sample acquisition mode,
typical
Absolute measurement of
any wavef orm point, and
High, Low, Max, and Min
measurements
±[(1.0% × | reading -- net
offset | ) + offset accuracy +
(0.13 div × V/div sett ing) +
0.6 mV]
Delta voltage measurement
between any two points
acquired under the same
setup and ambient condi-
tions, and all other auto-
matic m easurem ents
±[(1.0% × | reading | ) +
(0.26 div × V/div sett ing) +
1.2 mV]
Net offset = offset -- (posi tion × volts/division) and is
expressed in volts
n Average acquisition
mode (≥16 averages)
Absolute measurement of
any wavef orm point, and
High, Low, Max, and Min
measurements
±[(1.0% × | reading -- net
offset | ) + offset accuracy
+(0.06 × V/div)]
Delta voltage measurement
between any two points
acquired under the same
setup and ambient condi-
tions, and all other auto-
matic m easurem ents
±[(1.0% × | reading | ) +
(0.1 div × V/div setting) +
0.3 mV]
Net offset = offset -- (posi tion × volts/division) and is
expressed in volts
Nonlinearity, typical < 1 LSB differential, < 1 LSB integral, independently
based
