Tektronix TDS7054 Service Manual

Performance Tests
TDS7104 & TDS7054 Service Manual
4-31
TDS 7000 Test Record (Cont.)
Instrument Serial Number: Certificate Number:
Temperat ure: RH %:
Date of Calibration: Technician:
TDS7000 performance test MaximumOutgoingIncomingMinimum
CH3 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.6805 V __________ __________ -- 11.5195 V
CH3 1.01 V Vert scale setting,
--5 Div position setting, +10 V offset
+ 17. 621 V __________ __________ + 18.379 V
CH3 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.379 V __________ __________ -- 17.621 V
CH4 5 mV Vert scale setting,
--5 Div position setting, +1 V offset
+ 1. 0355 V __________ __________ + 1.0445 V
CH4 5 mV Vert scale setting,
+5 Div position setting, --1 V offset
-- 1.0445 V __________ __________ -- 1.0355 V
CH4 200 mV Vert scale setting,
--5 Div position setting, +10 V offset
+ 11.5195 V __________ __________ + 11.6805 V
CH4 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.6805 V __________ __________ -- 11.5195 V
CH4 1.01 V Vert scale setting,
--5 Div position setting, +10 V offset
+ 17. 621 V __________ __________ + 18.379 V
CH4 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.379 V __________ __________ -- 17.621 V
