Using Frame Picture Generator
Using the Fram
e Picture Generator menus
The M enu bar displays the names of the fi ve pull-down menus: File, Build,
Settings, Window, and Help. This section describes the function of each selection
in these menu
s.
File menu
The File menu contains commands for managing file operations and for exiting
the Frame Picture Generator application. The following table describes each
of the File
menu commands.
Table 5: Frame Picture Generator File menu commands
Command
Function
Open Opens a bitmap file. When you select a bitmap file, the image is
displayed in the BMP View window.
Save Frame Bmp As Saves the frame bitmap image displayed in the FrameBMP
View window as a bitmap file.
Save Pic Bmp As Saves the frame picture image displayed in the PicBMP View
window as a b itmap file.
Exit
Exits the Frame Picture Generator application.
Buil
dmenu
The Build menu contains commands that create a frame bitmap file or frame
picture fi le and convert a frame picture file to a bitmap file. The following table
describes each of the Build menu commands.
Tab
le 6: Frame Picture File Build menu commands
Command
Fun
ction
Bu
ild Frame Bmp
Converts the bitmap image displayed in the BMP View w indow
to the bitmap file with the specified video format size.
Build Pic File
Converts the frame bitmap file displayed in the FrameBMP View
w
indow to the frame picture file (.pic) that can be u sed by the
TG8000.
Since the AVG7 module outputs a signal using the 2-time over
sampling technique, one pixel of a bitmap image corresponds
to two samples of the signal. T herefore, when creating a frame
picture file for the AVG7 module, the application uses each pixel
of a bitmap image twice.
Build Pic Bmp
Converts the selected frame picture file (.pic) to the bitmap
file and displays its image in the PicBMP View window. Note
that this command cannot reproduce the original bitmap file
completely because the data of the frame picture file is changed
when it is converted from the bitmap file. This command is useful
when you want to check any frame picture images on the PC.
TG8000 Multiformat Test Signal Generator PC Tools Technical Reference 13
