Tektronix WVR6020 User Manual

Incoming Inspection
Table 62: Required test equipment for incoming inspection (cont.)
Test equipment Requirements Example
NTSC Black Tektronix TG2000 with B G1 and additional
modules indicated below.
1080i 59.94 HD signals required for
option HD:
100% color bars
10-bit shallow ramp
SDI Matrix Split Field Pathological Signal
100% sweep
HDVG1 module for TG2000 (Embedded
audio needed for audio options AD, DS,
DDE)
525/270 SD signals required for option
SD:
100% color bars
10-bit shallow ramp
SDI Matrix Split Field Pathological Signal
100% sweep
DVG1 module for TG2000 (Embedded
audio needed for audio options AD, DS,
DDE)
SDI serial digital video test generator,
with embedded audio and composite
signal source
Composite signals required for Option
CPS:
NTSC SMPTE bars
AVG1 module for TG2000
Dual Link
TG700 with HDLG7 module
AV Delay
TG700 with DVG7 module
AES Audio Signal Generator
48kHz, 24 bit word length signals
Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
AES Audio Signal Analyzer Rohde & Schwarz UPL06, Tektronix
AM700.
Analog Audio Signal Generator Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
Video Test Signals SDI 525 10-bit shallow ramp
SDI 525 100% sweep
NTSC black
NTSC SMPTE bars
Provided by Tektronix TG2000 as
specified above
LTC generator Horita TG-50 or Adrienne AEC-Box-28
Voltmeter Fluke 87 or equivalent
15-pin Dsub male connector and cable Used to m ate with the ground closure port
(See Figure 1 on page 82.)
Computer and ethernet cable
Used to test Ethernet connection
