Assembling the columns
GB
Instructions for Stainless Steel Vertical Column Installation
Height 2.60 m for lorries and cars (example instal-
lation. Please verify the necessary column height
during the design phase.)
+ Fix the door intercom or the module in question
to the column. To do so, please use the hexagon
socket screws provided in the door intercom station/
frame box. Use a clamping plate (cf. page ) to fix
the door intercom station's lower end.
Using the clamping plate, fix the two cover plates
mm and mm with a chamfer at the top and
bottom to the lower end of the door intercom station.
The required hexagon socket screws are included
with the cover plate.
Using the clamping plate, mount the cover
panel with the chamfer on the top side in a way that
the straight cut edge of the closing module points
towards the column base. The chamfered edge points
towards the Behnke door intercom station or towards
the module frame. Use a second clamping plate to fix
the lower edge of the cover panel. The M hexagon
socket screws required for this purpose are included
in the closing module box.
Use the cover panels without chamfer to close the
remaining column orifice. In case the cover panel is
too long, please shorten it accordingly. Please mind
the column base width of mm. The cover plate
should be inserted approx. mm into the base of the
column. The M hexagon socket screws required for
this purpose are included in the closing module box.
Mount the suitably shortened cover plate with the
drill holes facing upwards. The lower end is inserted
into the orifice of the column base. The dimensions
of the column base on page must be observed.
Directly screw the door inter-
com station into the column
Clamping plate to x the door
intercom station and the rst
cover plate (l=mm)
Clamping plate to x the sec-
ond cover plate (l=mm)
Clamping plate to x the next
door intercom station
Clamping plate to x the cover
plate (l=mm) with a
chamfer on one side
Clamping plate to x the
cover plate (l=mm)
without chamfe. If necessary,
shorten the cover plate before
mounting.
3.2. Column with two Behnke door intercom stations
Amplier W
- or -
resp.
W
Cars
First door intercom station (Lorries)
We recommend broadband loud-
speakers as well as additional W
ampliers
Second door intercom
station (Cars)
We recommend broadband
loudspeakers as well as
additional W ampliers
