TMS-MA Telecor Media Source Model A Installation Manual 23
Appendix 1. Specifications
Inputs: USB drive
SD/MMC memory card
FM tuner
AUX input
Bluetooth
Outputs: 1 x fixed audio output
Frequency range: FM 87.5 ~108.0 Mhz
Channel step: FM 50 kHz
Intermediate frequency: FM 10.7 MHz
Sensitivity: FM 2 μV at 30 dB S/N
Signal to noise ratio: FM >60 dB
Output level: 0 dB/600 ohm
Bluetooth version: 4.2
Power supply: DC+5V, 2A
Dimensions (W x H x D): 19.0” x 1.7” x 4.3” (483 x 44 x 110 mm)
Color: Black
Net Weight: 3.8 lbs (1.76 kg)
Operating temperature range: 10-40ºC (50-104ºF), 0-90% relative humidity,
non-condensing
