Telefunken P5 - Technical Specifications

Technical specifications
28
Technical specifications
Unit dimensions
(width x depth x height) 355 x 236 x 145 mm
Weight: approx. 1.85 kg
Voltage: 230 V alternating current, 50 Hz,
13 W
Output rating: 2 x 1.2 W RMS
Ambient conditions: +5 C to +35 C
5 % to 90 % relative humidity
(non-condensing)
Radio:
Receiving frequencies:
Aerial:
FM 88–108 MHz
MW 540–1600 kHz
FM telescopic aerial
MW aerial integrated
CD
Laser:
Converter:
Frequency range:
655 nm wavelength, Class 1
1 bit D/A, 8 x oversampling
100 Hz to 16 kHz
Battery operation DC 12 V,
8 x 1.5 V, BABY, LR14/C
Headphone/AUX socket: 3.5 mm
We reserve the right to make technical modifications and correct errors. The dimensions are approximate values.
Directives and standards: This product complies with the Low Voltage Directive (2006/95/EC), the EMC Directive (2004/108/EC)
and the CE Mark Directive.
