TelePost LP-PAN - Parts List

4
Parts List - Subject to change without notice. Pictures shown at end of parts list.
Pre-installed SMT parts
Quantity
Designation
Description
5
C5,11,18, 31, 39
0.01uF
2
C4, 6
0.1uF
1
C7
1uF
1
C9
0.22uF
1
L4
10uH
1
L8
12uH
0
L9,10
0.11uH (alternate to L11,12)
2
L11, 12
0.11uH
2
R1, 3
1K 1%
1
R4
4.7K 1%
1
R5
200 ohm 1%
2
R6, 7
499 ohm 1%
2
R8, 28
49.9 ohm 1%
1
T3
Toroid XFMR 1:1
1
T4
Toroid XFMR 4:1
1
U11
ADCMP600 Comparator
1
U2
74HC/HCT163 Counter
2
U4,7
LT6231 Low Noise Op-Amp
1
U5
AD8007 Transconductance Amplifier
1
U8
SN74CBT3253D 4x2 Analog Multiplexer
Through-Hole Parts
Quantity
Designation
Value
1
C1
33pF ceramic disc (marked 33) Fig. 3
6
C2,3,8,20,33,42
0.1uF monolithic (marked 104) Fig. 1
--
C10
Not used
1
C12
18pF ceramic disc (marked 18) Fig. 3
K2: 81pF (marked 81)
1
C13
10pF ceramic disc (marked 10) Fig. 3
K2: 68pF (marked 68)
8
C14,16,22,24,27,29,
32,37
0.01uF ceramic disc (marked 103) Fig. 3
5
C15,17,23,25,38
1uF (25V electrolytic) Fig. 2
1
C19
100uF (25V electrolytic) Fig. 28
2
C21,28
Kenwood: 220pF( 221), 10.7MHz: 0.001uF
(102), K3/K2/Orion: None
1
C26
10uF (25V electrolytic) Fig. 2
1
C30
47pF SM (47) Fig. 4, 10.7MHz: 22pF(22)
2
C34,35
4-20pF trimmer cap Fig. 19
1
C36
56pF ceramic disc (marked 56) Fig. 3
1
C40
0.001uF ceramic disc (102) Fig. 3
2
C41,43
3300pF ceramic disc (332) Fig. 3
Kenwood/Orion: 2700pF(272), K2: 0.01uF(103)
10.7MHz: 0.001uF(102),
1
D1
Green LED Fig. 9
1
D2
1N4148 Fig. 18
1
J1
Insulated BNC connector Fig. 17
2
J2,13
3.5mm Stereo Audio Jack Fig. 20
1
J3
RCA Jack Fig. 21
1
J11
2.5mm DC Power Connector Fig. 7
4
2-pin Jumper Fig. 11
3
JP1-3
2-pin Header Fig. 11
1
JP4
3-pin Header Fig. 11
