Teletek electronics ECLIPSE 8 - Assigning Attributes for User Proxy Card

ECLIPSE 8/16/32/99 Series – User Operation Manual
33
5.11 Assigning Attributes for user proxy card
In menu “1. USERS – xx. User – 06. Proxy Options” or Address 10, the manager sets
rights to user cards for arming/disarming the system via proximity card reader.
In text menus the user will see the options as a list. To enable an option, press button “1”
– a symbol “” is assigned in front of the option. To disable an option, press button “0”. To
scroll over the available options, use the arrow buttons.
In address menus the options are corresponding to the numbers from the table below:
User attributes for work with a proxy reader:
Text menus
Address option
Description
DISARM ENB
1
Disarming all areas associated to this user.
ARM DISABLED -
Arming is not allowed with this code (both options 2 and 3
are disabled).
STAY ARM
2
STAY ARM mode for all areas associated to this user.
FULL ARM
3
FULL ARM mode for all areas associated to this user.
SLEEP ARM
2+3
SLEEP ARM mode for all areas associated to this user.
Notes:
Only one arming mode can be used with every proxy card.
By default, all users are allowed to arm and disarm the system in SLEEP ARM mode.
Depending on the keyboard used, the visualization on screen is as follows:
LCD 32 and LCD 32 Sensitive (address menus)
By pressing a digit buttons with the number of an option, it is alternatively enabled or
disabled. The option is enabled when the digit is visible on screen.
The option is disabled
when the symbol “
*
” is shown.
LED 32
By pressing a digit buttons with the number of an option it is alternatively enabled or
disabled. The option is enabled when the digit is lit on the display.
The option is disabled
when the digit is not lit.
Manager code
Address
Assigning
options
User
number
The card can disarm and arm in
SLEEP ARM mode
The card can disarm and arm in
FULL ARM mode
The card can disarm and arm in
SLEEP ARM mode
The card can disarm and arm in
FULL ARM mode
