LCD62 Keypad User Manual 9
LED Indication
LED Lit Blinking
Ready (green) System ready Programming mode
Arm (red) System armed Entry or exit time
Trbl (orange) - Technical problem
Sound Indication
There are seven different sound combinations that indicate
seven different conditions:
Click
– single short beeps indicating button pressing
Confirm
– two long beeps indicating the system confirmation
to executed operation (arming, disarming, settings change,
etc.)
Reject
– single long beep indicating incorrectly executed
operation
Entrance time
– continuous beep indicating intrusion into the
entrance zones.
Exit time
– short beeps indicating the system is armed and
the user is required to leave the zone. Ten seconds before
the exit time is over beeps frequency is increased.
Trouble
– two short beeps indicating problem with the
system (battery low, no supply voltage, etc.)
Chime
– short beeps with subsequently increasing period
indicating intrusion into a zone with a “Chime“ option
activated
