Televes 5863 - 1.- TECHNICAL SPECIFICATIONS

28
Simple IF Proces. (Ref. 5863) Triple IF Proces. (Ref. 5864)
Input frequency margin: 950 to 2150 MHz
Output frequency margin: 950 to 2150 MHz
Tuning frequency steps of converting oscillator: 1 MHz
Output impedance: 75 Ohm
Input return losses: > 10 dB
Output return losses: > 10 dB
BW of selectable channel a -1 dB: 27 MHz / 36 MHz (switchable)
Input level: min:-50 dBm max:-20 dBm
Output level: max:-20 dBm (adjustable >15 dB)
Level regulator: Yes
Powering voltage of LNB (V): 13V / 17V / OFF
22 kHz / OFF
Consonmation: (5V) 360 mA 1 A
(15V) 150 mA 150 mA
Protection index: IP20
Note: Controllable via l CDC, version 2
1.- TECHNICAL SPECIFICATIONS
1.1.- IF Processor - Simple (ref. 5863), Triple (ref.5864)
User manual IF Processor
