Televes TDT+ - Amplifier Technical Specifications; Amplifier 5075; Amplifier 4510; Amplifier 4514

5
User manual TDT +
ENGLISH
5
Frequency range: 47 ... 862 MHz Connector: “F”
Gain: 45 ± 2 dB Powering: 15 V
Regulation margin: 20 dB Consumption at 15 V : 800 mA
Output level (60 dB): 105 dBµV (42 CH CENELEC) Test socket: -30 dB
Frequency range: 47 ... 862 MHz Connector: “F”
Gain: 44 dB Powering: 230 V~
Regulation margin: 20 dB Consumption at 24 V : 430 mA
Output level (60 dB): 104 dBµV (42 CH CENELEC) Test socket: -30 dB
24V (0,55 A)
Mains voltage: 220 ± 15 % V~ Maximum current: 18V (0,8 A)
Output voltages: 5, 15, 18, 24V 15V (4,2 A)
(1)
5V (6,6 A)
1 . 2.- Amplifiers - Technical specifications
1 . 3.- Power supplies - Technical specifications
Amplifier
5075
Amplifier
4510
Frequency range: 47 ... 862 MHz Connector: “F”
Gain: 44 dB Powering: 110 V~
Regulation margin: 20 dB Consumption at 24 V : 430 mA
Output level (60 dB): 104 dBµV (42 CH CENELEC) Test socket: -30 dB
Amplifier
4514
Power
supply
5025
(2)
24V (0,55 A)
Mains voltage: 230 ± 15 % V~ Maximum current: 18V (0,8 A)
Output voltages: 5, 15, 18, 24V 15V (4,2 A)
(1)
5V (6,6 A)
Power
supply
5029
24V (0,55 A)
Mains voltage: 120 ± 15 % V~ Maximum current: 18V (0,8 A)
Output voltages: 5, 15, 18, 24V 15V (4,2 A)
(1)
5V (6,6 A)
Power
supply
5030
(3)
(1)
If you are using 24V and/or 18V, you need to take the power consumed by these away from the 15 V power.
(2)
In compliance with KTL norms.
(3)
In compliance with UL norms.
