Televes TDT+ - Technical Specifications; TDT+ Ref. 5023

4
User manual TDT +
1.- TECHNICAL SPECIFICATIONS
1.1.- TDT+ Ref. 5023
Input frequency: 950 - 2150 MHz Through losses: < 1.5 dB typ.
Input level: -65 to -25 dBm IF bandwidth: 36MHz
Locking margin: ± 5 MHz Symbol rate: 1.5 to 42.5 Mbaud
Frequency steps: 1 MHz Convolutional code: Viterbi 1/2, 2/3, 3/4, 5/6, 7/8
Input-output connectors: “F” female Block code: Reed Solomon (204,188)
Input impedance: 75 ohm. Roll-off factor: 35%
LNB powering: 13/17V / OFF De-interleaving: ETS300241
22KHz (ON/OFF) De-scrambling: ETS300421
Input VSWR: 10 dB min
Modulation format: 16, 32, 64, 128, 256 QAM, Scrambling: DVB ET300429
Symbol rate: 7,2 Mbaud max. Interleaving: DVB ET300429
Roll-off factor: 15% Bandwidth 8,3 MHz max.
Block code: Reed Solomon (188, 204) Output spectrum: Normal / Inverted (selec.)
Output frequency: 46 - 862 MHz (Selec.) Through losses: < 1.5 dB typ.
Frequency steps: 1 MHz Return losses: > 12 dB typ.
Phase noise: 90 dBc/Hz @10KHz typ. Input-output connectors: “F” female
Output level: 80 ... 65 dBµV Output impedance: 75 ohm.
Adjustable output level: 15 dB min.
Consumption: 5V : 0,85 A
15V : 0,28 A.
18V : 0,3 A max. ( For feeding LNB)
QPSK
demodulator
UP
Converter
QAM
modulator
The technical specifications are defined with a maximum room temperature of 40º C.
General
