User manual TDT +
2.- REFERENCE DESCRIPTION
Ref. 5023 .... TDT + (46 - 862 MHz)
Ref. 5075 .... T-05 amplifier (47 - 862 MHz)
Ref. 4510 .... Kompact amplifier (47 - 862 MHz)
Ref. 4514 .... Kompact amplifier (47 - 862 MHz)
Ref. 5025 .... Power supply unit (220 V ± 15 % - 50/60 Hz)
(24 V - 0,55 A)
(In compliance with KTL) (18 V - 0,8 A)
(15 V - 4,2 A)
(1)
(5 V - 6,6 A)
Ref. 5029 .... Power supply unit (230 V ± 15 % - 50/60 Hz)
(24 V - 0,55 A)
(18 V - 0,8 A)
(15 V - 4,2 A)
(1)
(5 V - 6,6 A)
Ref. 5030 .... Power supply unit (120 V ± 15 % - 50/60 Hz)
(24 V - 0,55 A)
(In compliance with UL) (18 V - 0,8 A)
(15 V - 4,2 A)
(1)
(5 V - 6,6 A)
Ref. 7234 .... Universal programmer
Ref. 5071 .... Wall support (10 mod. + PSU)
Ref. 5239 .... Wall support (12 mod. + PSU)
Ref. 5173 .... Blank plate 15 mm
Ref. 4061 .... “F” 75 ohm load
Ref. 5072 .... Universal cabinet
Ref. 5301 .... 19” subrack
Ref. 5073 .... Blank plate 35 mm
(1)
If you are using 24V and/or 18V, you need to take the power used by these away from the 15 V power.
