Telex Audiocom US-2000 - DIP SWITCHES (SW2) FUNCTIONS

DIP Switches (SW2)
Table 1. SW2 Functions and Settings
SWITCH
NUMBER SWITCH FUNCTION
DEFAULT
SETTING
1 Headset audible key press
beep on/off
On: No beep
Off: Beep activated
Off
2 Mic Kill on/off (Enables/disables
another user station from killing
the microphone on this station)
On: Mic kill enabled
Off: Mic kill disabled
On
3 Channel 1 20-kHz call/send
On: Enable 20 kHz signalling
Off: Disable 20 kHz signalling
On
4 Channel 2 Program Interrupt
On: Program interrupted
during talk
Off: No program interrupt
Off
5 Channel 1 Program Interrupt
On: Program interrupted
during talk
Off: No program interrupt
Off
6 Left Earpiece Source
On: Both channels
Off: Channel 2 only
On
7 Right Earpiece Source
On: Both channels
Off: Channel 1 only
On
8 Channel 2 20-kHz call/send
On: Enable 20 kHz signalling
Off: Disable 20 kHz signalling
On
NOTE:
The Program Interrupt feature individually controls the program
audio for each channel. When the Program Interrupt feature is
enabled, program audio is shut off on that channel when the
Talk
key is pressed. If the Program Kill feature is enabled for a chan-
nel, the Program Interrupt feature will have no effect on that
channel.
11
