Telguard TG-7A - RJ-45 Jack Pin Assignments; DC Terminal Strip Pin Assignments; Main Terminal Strip Pin Assignments

TG-7 Cellular Series Installation & Operating Guide 28 56053501 Rev A © 2022 Telguard
RJ-45 Jack Pin Assignments
Jack
Connects To
Pin Assignment
Function
Status LED Reference
Black
(J13)
Digital Dialer
input/output
of host alarm
panel (DACT).
1 = Brown R1
2 = Blue
4 = Green R (Ring)
5 = Red T (Tip)
7 = Orange
8 = Gray T1
Connects alarm
panel to
communicator
for transmitting
alarm signals to
TCC.
If PPF is ENABLED,
STC LED 2 will flash 7
times when alarm panel
is not detected.
Gray
(J14)
Incoming Telco
RJ-45 jack.
1 = Brown R1
2 = Blue
4 = Green R (Ring)
5 = Red T (Tip)
7 = Orange
8 = Gray T1
Connects Telco
line to
communicator.
STC LED 2 will flash 3
times when Telco
voltage is lost.
DC Terminal Strip Pin Assignments
Terminal
Strip Pin
Definition
Connects To
Function
LED
Reference
Note
1 GND
2 DC
DC Power
input
12- or 24-VDC
Regulated Source
(or TG-PEM)
Provides
power to
communicator
Power LED 8
on for valid
power
Consumption rates vary
based on input voltage
used
Main Terminal Strip Pin Assignments
Terminal
Strip Pin
Definition
Connects To
Function
Status LED
Reference
1 STC2
2 STC2
Supervisory Relay
Trip output for
programmable
trouble conditions.
Normally Closed.
24-hour trip
zone input
on alarm
panel.
Enables transmission of
programmed supervisory
trouble code (see diagram
or installation section).
STC LED 2
3 STC1
4 STC1
Supervisory Relay
Trip output for
programmable
trouble conditions.
Normally Open.
24-hour trip
zone input
on alarm
panel.
Enables transmission of
programmed supervisory
trouble code (see diagram
or installation section).
STC LED 2
5 GND
6 IN
Trip Ground and
Trip Input
External trip
relay.
Allows an external relay to
trigger an alarm signal.
LED 7
