Telguard TG-7FP Installation & Operating Guide 21 56052401 Rev A
Troubleshooting Quick Reference Table
Telguard Event
LED Indication
Relay
Output
Radio
Message
Internal Action
STC *
(System
Trouble
Conditions)
LPF
PWR LED 8 is off. STC
LED 2 flashes
continuously 1 time.
Optional
Optional
Verify connection from
panel aux power and
correct.
NSC
STC LED 2 flashes
continuously 4 times.
Optional
None
Continue to validate
signal strength, NSC will
restore when signal
returns.
RFC
STC LED 2 flashes
continuously 5 times.
Optional
None
Wait for RFC restoral.
DTF
STC LED 2 flashes
continuously 6 times.
Yes
Yes
Internal dial tone voltage
supply circuit failure.
PPF
STC LED 2 flashes
continuously 7 times.
No
Yes
Wait for PPF restoral.
Not Activated
Activation LED 1 off.
Yes
None
The communicator will
not function until the
first signal is sent to the
TCC to activate the unit.
Automatic Self-Test
Radio LED 5 flashes
during transmit.
None
Yes
(Self-test)
Send Self-test
information to central
station via TCC, return
to ready state.
Telguard Check Status
Radio LED 5 flashes
during transmit.
None
Yes
(Status data)
Send Status data to the
TCC for review.
Telguard Enable and
Configuration Update
Radio LED 5 flashes
during transmit.
None
Configuration
Data
The TG-7FP sends setup
configuration to the TCC
and switches to READY
state to begin operation.
Disable TX
(Initiated by TCC)
Radio LED 5 flashes
when transmitting.
Yes
Yes
(Status data)
TX capability is disabled
until further notice. The
TG-7FP can still receive
radio signals from the
TCC.
* If several trouble conditions are present, the STC LED will flash all applicable indications in sequence.
