The available connectors are:
• Main RF antenna (ANT)
• RX Diversity Antenna (DIV)
• GNSS Antenna (GPS)
Connecting cables between the module and the antenna must have an impendance of 50
Ω.
If the module impedance does not match, the RF performance is reduced significantly.
If the host device is not designed to use the module diversity or the GPS antenna,
terminate the interface with a 50Ω load.
7.3.2. Main GSM/WCDMA/LTE Antenna Requirements
The antenna for the LE910Cx-mPCIe device must meet the following requirements:
Item
Value
Frequency range
The customer must use the most suitable antenna band width to
cover the frequency bands provided by the network operator while
using the Telit module.
The bands supported by each variant of the xE910Cx module
family are provided in Section Product Variants and Frequency
Bands
Gain
Gain < 3 dBi
Impedance
50 ohm
Input power
> 33 dBm(2 W) peak power in GSM
> 24 dBm average power in WCDMA & LTE
VSWR absolute max
≤ 10:1 (limit to avoid permanent damage)
VSWR recommended
≤ 2:1 (limit to fulfill all regulatory requirements)
Table 23: Main GSM/WCDMA/LTE Antenna Requirements
7.3.3. Antenna Diversity Requirements
This product includes an input for a second Rx antenna to improve radio sensitivity. The
function is called Antenna Diversity.
Item
Value
Frequency range
The customer must use the most suitable antenna band width to
cover the frequency bands provided by the network operator while
using the Telit module.
