Teltonika RUT240 Installation Manual

Type
Product
Name
Summary and Datasheets
Cellular Router
RUT240
RUT240 cell router website
Omni-direction
al antenna
QuSpot
Link
External antenna with antennas in 4
directions. Utilized in urban environments
with lots of different tower locations nearby
Uni-directional
antenna
QuMax
Link
External antenna with single direction of
antenna. Strongest gain in one direction,
ideal for suburban and remote locations
Passive POE
injector - 24V
DC
UI
Passive
POE 24V
DC
Link
Used to power the RUT240 router, through
the LAN port. Warning: RUT240 does not
support standard POE, which would burn the
router. Only use this passive POE that’s 24V
DC output.
Network
Swiftlane uses AT&T as the primary provider for cellular connectivity. Please check the
general signal strength at the customer site, you can request this information ahead of
time from the customer or during your initial site assessment.

Teltonika RUT240 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	DC-HSPA+, UMTS
Data network	2G, 3G, 4G, EDGE, GPRS, GSM, LTE, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
EDGE multislot class	12
UMTS bands supported	850, 900, 2100 MHz
Number of simultaneous SIM cards	1
Antennas quantity	3
Antenna connector type	RP-SMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
Device type	Cellular wireless network equipment
Product color	Black
LED indicators	WLAN
Processor frequency	400 MHz
Product type	Tabletop router
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	83 mm
Height	25 mm
Weight	125 g
Dimensions (WxDxH)	83 x 74 x 25 mm
