Teltonika RUT240 Installation Manual

Mounting Considerations for External Antenna
External antennas should be mounted outside the building with minimal obstruction from
nearby buildings. Identify the location that balances ease of installation with the maximum
unobstructed views, in order to achieve best gain from the antenna
● Balance ease of installation with aesthetic considerations for the building, and
minimal obstructions from nearby building
● For uni-directional antenna, the mount provides a 45 degree rotation angle, in order
to adjust the antenna horizontally and align with the nearby tower
● Use cellmapper.net to identify nearby towers to ensure maximum gain on the
antenna
Height
In general, the taller the antenna is placed, the better it will perform. However, 10-12 ft is a
good installation height to start. This protects it from easy access to vandalism, while also
getting few obstructions to the nearby towers. You can connect the antenna and hold it up
at that height and check the signal strength indicators by connecting to the local
management dashboard over an IP connection. Follow the instructions below to get
familiar with the various parameters for signal strength.
Direction
Omni - directional antennas capture signal strength from all directions so they dont to be
pointing in any specific direction
Uni-directional antennas must be pointed in the general direction of the nearest cell towers
for AT&T. You can use https://www.cellmapper.net/ to insert the full address and look up
nearby 4G towers.

Teltonika RUT240 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	DC-HSPA+, UMTS
Data network	2G, 3G, 4G, EDGE, GPRS, GSM, LTE, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
EDGE multislot class	12
UMTS bands supported	850, 900, 2100 MHz
Number of simultaneous SIM cards	1
Antennas quantity	3
Antenna connector type	RP-SMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
Device type	Cellular wireless network equipment
Product color	Black
LED indicators	WLAN
Processor frequency	400 MHz
Product type	Tabletop router
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	83 mm
Height	25 mm
Weight	125 g
Dimensions (WxDxH)	83 x 74 x 25 mm
