Teltonika RUT360 User Manual

90
Field name
Sample
Explanation
1.
Enable
Enable/Disable
Enable proxy server based URL content blocking. Works with HTTP
protocol only
2.
Mode
Whitelist/Blacklist
Whitelist - allow every part of URL on the list and block everything
else. Blacklist - block every part of URL on the list and allow everything
else
3.
URL
content
example.com
Block/allow any URL containing this string. Example.com, example.*,
*.example.com
8.4 NTP
NTP configuration lets you setup and synchronize routers time.
Field name
Description
1.
Current System time
Local time of router.
2.
Time zone
Time zone of your country.
3.
Enable NTP
Enable system’s time synchronization with time server using NTP (Network Time

Teltonika RUT360 Specifications

General

Device type	Cellular network router
Reset button	Yes
Product color	Silver
LED indicators	LAN, Speed, WLAN
Housing material	Aluminum
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL)
Data network	3G, 4G
SIM card type	MiniSIM
SIM interface	1.8 V
Number of SIM cards	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antenna type	Internal
Antennas quantity	4
VPN support	DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
Security algorithms	IPSEC, IPSec
RAM type	LPDDR2
RAM capacity	0.128 GB
Processor model	QCA9531
Processor frequency	0.65 GHz
Processor manufacturer	Qualcomm
Ethernet LAN (RJ-45) ports	2
Power source type	DC
Power consumption (typical)	10.5 W
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	85 mm
Width	100 mm
Height	30 mm
Weight	247 g
