Temcoline T37 User Manual

www.temcoline.com
DIGITAL PID CONTROLLER
22
Initial value
11. Setting mode
1) General setting mode
The general setting mode is for changing environment parameters on ad hoc basis
and also for tuning performance enhancement and configuring other functionalities.
Display
Description
Setting range
Condition
Display general setting
mode
EU (0 ~ 100 %)
EU (0 ~ 100 %)
EU (0 ~ 100 %)
EU (0 ~ 100 %)
1 / 2
EU (0 %)
EU (0 %)
EU (0 %)
EU (100 %)
20.0 ℃
240 sec.
2 sec.
EUS (0.5 %)
NORMAL
480 sec.
EU (100 %)
EU (0 %)
1
50.0 %
60 sec.
D.I Option
in use
D.I Option
in use
Use Alarm 1
Integral time
OFF
PID control
(SSR or RELAY)
ON/OFF
control
ON/OFF
control
ALARM1
No. 21 selection
Use
retransmission
and select
PV or SV
Use Alarm 2
Always
PID control
PID control
PID control
- - -
0 ~ 999.9 ℃
OFF / 1 ~ 6000 sec.
OFF / 1 ~ 6000 sec.
-5.0 ~ 105.0 %
1 ~ 1000 sec.
EUS (0 ~ 100 %)
HALF / NORMAL
OFF / 1 ~ 9999 sec.
TC/RTD : _IN.H~_IN.L
DCV IN : _SL.H~_SL.L
( But, RET.H ＞ RET.L )
Set value 1 (SV1) setting
Set value 2 (SV2) setting
Set value of alarm 1 (AL1)
Set value of alarm 2 (AL2)
Selection of (SV1, 2) number
SV1, 2 proportional band (P)
SV1, 2 Integral time (I)
SV1, 2 Differential time (D)
SV1, 2 Manual reset (MR)
Cycle Time (P.I.D Control Only)
Hysteresis (ON/OFF control)
Select the operational method
of Hysteresis
Control loop break alarm (LBA)
Highest limit of retransmission
(RET.H)
lowest limit of retransmission
(RET.L)
