DIGIT
AL PID CONTROLLER
3. Dimensions and Panel cutouts
1) T32 (48x96 mm) Dimensions
2) T33 (96x48 mm) Dimensions
3) T34 (48x4
8 mm) Dimensions
9
T32 / T33 (96x48)
Panel cutouts
(Unit: mm)
(Unit: mm)
45
±0.5
92
±0.5
Min. 30
Min. 20
T34 (48x48) Panel cutouts
Min.17
Min.17
45
+0.5
-0
45
+0.5
-0
48.0
96.0
10.0
77.0
96.0
91.0
96.0
48.0
48.0
43.6
10.0
77.0
99.0
8.8
48.0
44.9
48.0
48.0
8
10
