DIGITAL PID CONTROLLER
21
9. Entering into "set menu" and Setting method
1) Input & Output type setting
① Input type setting : Select the desired input sensor type.
(setting code 1~33 / refer to P7, Input ranges)
② Output type setting : Select the desired output type.
Temcoline products are universalized input and output.
Please set up input and output type firstly and use when
install our unit.
When it is LEVEL 3, input/output set is
available.(Refer to p25) Setting menu
display limit(LEVEL) function)
more than 3 sec.
Press
once shortly
Press once shortly
Press
once shortly
LEVEL 1~3
※ If the P value is set to OFF even when the P.I.D control output 1, 2, or 3
is selected, it operates in the ON / OFF mode.
SETTING
CODE
CONTROL OUTPUT
RELAY ON/OFF CONTROL
SSR P.I.D CONTROL
SCR (4~20mA) P.I.D CONTROL
RELAY P.I.D CONTROL
0
1
2
3
INPUT(T.C) CODE TEMP. RANGE
K
J
E
T
R
B
S
L
N
U
C (W5)
D (W3)
1
2
15
16
3
4
5
6
7
8
17
9
10
-200 ~ 1370
-199.9 ~ 999.9
-200 ~ 1000
-199.9 ~ 999.9
-200 ~ 1000
-199.9 ~ 999.9
-199.9 ~ 400.0
0 ~ 1700
400 ~ 1800
0 ~ 1700
-200 ~ 900
-199.9 ~ 900.0
-200 ~ 1300
11
-199.9 ~ 400.0
14
-199.9 ~ 999.9
12
0 ~ 2300
13
0 ~ 2400
0~100 mV DC
-10~20 mV DC
1~5V DC
33
32
30
4~20mA DC
(Use 250Ω resistor)
20
22
21
23
-199.9 ~ 500.0
-200 ~ 500
-199.9 ~ 640.0
-200 ~ 640
Pt100Ω
(DIN, IEC)
JPt100Ω
(JIS, KS)
INPUT(T.C) CODE TEMP. RANGE
INPUT(V DC/mV DC) CODE
Press
once shortly
