TEMO 450 - Installation on Board; Installation of the Oarlock

ENG
18
TheoarlocksuppliedintheTEMO·450kitenablesmaximalmotor
eciency,whilekeepingtheinstallaonsecure.
1. INSTALLATION OF THE OARLOCK
The oarlock is designed to opmise the use of your TEMO
.
450 and
make it easier and safer to handle. We highly recommend
its use.
Warning:sometransomshavewaterghtnessproperes.Becarefulne-
vertodrillasurfacethatmustremainwaterght.
Theinstallaonmustbexedonaatsurface,vercalorhorizontal.
Onacleandryandsolidsurface(aluminium,wood,polyester),screwon
yourTEMOoarlockbyfollowingtheinstruconsbelow:
-Takeyourboatoutofthewaterandposionitonastable,atsurface.
-Getintoyourboatandstretchoutyourarmtobeinacomfortable
posion.Marktheappropriateposioningpointadaptedtoyourarm
lengthandyourposionontheboat.
-Youroarlockdoesnothavetobeedonthecenterlineofyourboat.
-Screwtheoarlockngontotheexteriorofthetransom,usingthe
screwsprovided;
-Thelowerseconoftheoarlock'smetallicaxlemustbealignedwith
thetopofthetransom.TheTEMO
.
450 mustbeabletoberaisedtothe
horizontalposion.
-Ifpossible,placetheoarlocksothattheTEMO
.
450isatabout30cm
abovethewater.TheopmalanglebetweentheTEMO
.
450 and the
watersurfaceis30°max.
Ifthereisnotransom,theoarlockcanbexedonthesidesofthetender.
You can also nd informaon on the installaon of this oarlock on
our website, www.temofrance.com or on our Youtube channel,
youtubeTEMOFrance.
INSTALLATION ON BOARD
WARNING
Only use the TEMO oarlock.
Dimension of the oarlock
Installation diagram
about 30cm
3à 5 cm
Max 30°
