4G680V2.0
9
transfer.
3
WPS
For the WPS connection will shine.
4
Internet
Light up in green when Internet is enabled. Blink when data
transfer.
5
Signal
Show signal strength.
Number
Connections
Description
6
Power
Turn on/off the router.
7
Power Adapter
Connect Power to DC-Jack 12V/1A Power Adapter. Using
power supplies with a different voltage from the one included
with the 4G680V2.0 will cause damage and void the warranty.
8
LAN
LAN ports provide connections to Ethernet enabled devices.
9
WAN/LAN
If the WAN is set to the WAN Mode, will be as the WAN
interface, you can dial the DSL module; If WAN set to LAN
MODE, will be a LAN interface
10
TEL
Connect the telephone
Number
Connections
Description
11
RESET
Press the reset button 3 seconds to restore the device to its
factory default settings.
12
WPS
Click this button to start WPS encryption.
13
SIM
Insert SIM card to automatically identify registration
