99
Parameter
Description
Alternate DNS Server
It specifies the secondary DNS address of the router used to assign to the clients. It is
an optional field and is left blank by default.
11.4 Remote web-based management
11.4.1 Overview
Generally, the web UI of the router can only be accessed on devices that are connected to the
router by a LAN port or wireless connection. When you encounter a network fault, you can ask for
remote technical assistance, which improves efficiency and reduces costs and efforts.
To access the configuration page, log in to the web UI of the router, and choose Administration >
Remote Web-based Management.
By default, this function is disabled. When this function is enabled, the page is shown as below.
Parameter description
Parameter
Description
Remote Web-based
Management
It is used to enable or disable the remote management function of the router.
Management IP
Address
It specifies the IP address of the host which can access the web UI of the router
remotely.
All: It indicates that hosts with any IP address from the internet can access the web
UI of the router. It is not recommended for security.
Specific: Only the host with the specified IP address can access the web UI of the
router remotely. If the host is under a LAN, ensure that the IP address is the IP
address of the gateway of the host (a public IP address).
Port
It specifies the port number of the router which is opened for remote management.
Change it as required.
The port number from 1 to 1024 has been occupied by familiar services. It is strongly
recommended to enter a port number from 1025 to 65535 to prevent confliction.
Remote management can be achieved by visiting http://the WAN IP address of the
router:port number. If the DDNS host function is enabled, the web UI can also be
accessed through http://the domain name of the routers WAN port:port number.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda AC7 and is the answer not in the manual?

Tenda AC7 Specifications

General IconGeneral
VPN supportIPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
USB portNo
Ethernet LAN (RJ-45) ports4
Transmit power30 dBmW
Antennas quantity5
Antenna gain level (max)6 dBi
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, System, WAN
Output current1 A
Output voltage9 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Package typeBox
Package weight860 g
Number of products included1 pc(s)
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)867 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
Firewall securityForbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithmsWPA, WPA-PSK, WPA2, WPA2-PSK, WPS
CertificationCE, FCC, RoHS
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth141.5 mm
Width220 mm
Height49 mm
Weight360 g
