Tenda AC7 User Manual

63
9.2 IPTV
9.2.1 Overview
If the IPTV service is included in the broadband service you purchased, you can enable the IPTV
function to enjoy both internet access and IPTV programs through the router at the same time.
To access the configuration page, log in to the web UI of the router, and choose Advanced > IPTV.
This function is disabled by default. When it is enabled, the page is shown as below.
Parameter description
Parameter
Description
IPTV
It is used to enable or disable the IPTV function of the router.
When this function is enabled, the port 3/IPTV can be used only as an IPTV port to be
connected to an IPTV set-top-box.
VLAN
It specifies the VLAN ID of your IPTV service.
⚫
If you do not have any information about VLAN provided by your ISP, please keep Default.
⚫
If you are using the IPTV service in Shanghai, choose Shanghai VLAN and choose the
proper VLAN ID.
⚫
If you have VLAN ID from your ISP, please choose Manual VLAN and enter the VLAN
value.
9.2.2 Watch IPTV programs through the router
Scenario: The IPTV service is included in your broadband service. You have obtained the IPTV
account and password from your ISP, but no VLAN information.
Goal: Be able to watch IPTV programs through the router.
Solution: You can configure the IPTV function to reach the goal.
Internet

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
