Wireless Modem Router User Guide
Depending on the type of connection, you are prompted to enter your ISP settings, as shown in the following table:
Internet Connection Type
ISP Information
PPPoE
PPPoA
Enter the ISP login user name and password. If you cannot locate this information, ask your ISP
to provide it.
IPoE
Dynamic IP
No entries are needed.
Static (Fixed) IP
Enter the assigned IP address, subnet mask, and the IP address of your ISP’s primary DNS
server. This information should have been provided to you by your ISP. If a secondary DNS
server address is available, enter it also.
IPoA
Static (Fixed) IP
Enter the assigned IP address, subnet mask, and the IP address of your ISP’s primary DNS
server. This information should have been provided to you by your ISP. If a secondary DNS
server address is available, enter it also.
_________________________________________________________________________________________________
Note:
If your country and/or your ISP are not covered on the home page, please click the button on the
home page and then select Advanced Setup -> Layer2 Interface -> ATM Interface and then click Add there to manually
configure the VPI and VCI. If you cannot locate this information, refer to Appendix 4 VPI/VCI List or ask your ISP to
provide it. For more information, see To set up the ATM interface and To setup WAN Service for ATM Interface.
_________________________________________________________________________________________________
e. After you configure all the above settings, click OK to save and apply them.
f. Test Internet Connectivity
Launch a web browser and enter www.tendacn.com. If the webpage is opened, you are connected to Internet.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda D151 and is the answer not in the manual?

Tenda D151 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
USB portNo
Ethernet LAN (RJ-45) ports1
Antenna gain level (max)5 dBi
Product typeTabletop router
Product colorWhite
LED indicatorsPower, System, USB, WLAN, WPS
Output current1 A
Output voltage9 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Bandwidth (first)2.4 GHz
Security algorithmsSSID, WDS, WPA2-PSK
Cables includedLAN (RJ-45)
CertificationFCC / CE / RoHS
Weight and Dimensions IconWeight and Dimensions
Depth171.61 mm
Width111.16 mm
Height34.47 mm
