Wireless Modem Router User Guide
UPnP
Print Server
Storage Service
Interface Grouping
IP Tunnel
Certificate
Multicast
IPTV
4.2.1 Layer2 Interface
Click Advanced Setup -> Layer2 Interface to enter the Layer2 Interface screen.
This router provides two Layer2 Interfaces:
- ATM Interface for ADSL broadband Internet service
- ETH Interface for connecting to Internet via an Ethernet cable.
By default, system applies the ATM Interface (ADSL uplink).
If you directly connect to the ADSL line via a phone cable, first refer to To set up the ATM interface and then skip to
To setup WAN Service for ATM Interface.
Or if you connect to Internet via a fiber/cable modem using an Ethernet cable, first refer to To set up the ETH interface
and then skip to To setup WAN Service for ETH Interface.
To set up the ATM interface
Select ATM Interface and click Add to configure it.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda D151 and is the answer not in the manual?

Tenda D151 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
USB portNo
Ethernet LAN (RJ-45) ports1
Antenna gain level (max)5 dBi
Product typeTabletop router
Product colorWhite
LED indicatorsPower, System, USB, WLAN, WPS
Output current1 A
Output voltage9 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Bandwidth (first)2.4 GHz
Security algorithmsSSID, WDS, WPA2-PSK
Cables includedLAN (RJ-45)
CertificationFCC / CE / RoHS
Weight and Dimensions IconWeight and Dimensions
Depth171.61 mm
Width111.16 mm
Height34.47 mm
