Tenda I-WL-O3 User Manual

139
Parameters description
Name
Description
IP Address of Peer AP
It specifies the LAN IP address of peer CPE. You can enter it manually or select an IP
address from the drop-down list if there are devices connected to the CPE.
IP Address
If the IP Address of Peer AP is set to Manual, you need to enter the LAN IP address
of peer CPE in the box manually.
HTTP Port
It specifies the HTTP service port number of peer device, which is used to establish
speed test connection based on TCP/IP. Default: 80. You are recommended to keep
the default value.
User Name
It specifies the login user name and password of peer device.
Password
Test Group
It specifies the number of test connection launched.
Direction
It specifies the test speed direction.

RX (Receive): only test the speed that the peer device transmits data to this

Tenda I-WL-O3 Specifications

General

Brand	Tenda
Model	I-WL-O3
Category	Network Router
Language	English
