29
4.3 Example of AP mode and client mode
Network requirement
You want to use two CPEs to establish a CCTV surveillance network.
A CPE can support several IP cameras. The maximum number of IP cameras can be calculated with the
following formula:
Number of IP cameras=Transmitted/received rate of the CPE / Data rate of IP camera
Solution
− Set CPE1 to the AP mode, and connect it to the NVR.
− Set CPE2 to the Client mode, and connect it to IP cameras.
Network topology
Configuration procedures
Step 1 Set CPE1 to AP mode.
1. Log in to the web UI of CPE1, and choose Quick Setup to enter the configuration page.
2. Select AP mode and click Next.
