55
5. Click Save, and wait until the device reboots to activate the settings.
Step 2 Perform Step 1 above to set CPE3 to Repeater mode, and bridge to CPE1.
Step 3 Set CPE1 to Repeater mode and bridge to CPE2 and CPE3.
1. Start a web browser on the computer connected to CPE1, and visit 192.168.2.1.
2. Choose Quick Setup to enter the configuration page.
3. Select Repeater mode, and click Next.
4. Select SSIDs of CPE2 and CPE3, and click Next at the bottom of the page.
If there are multiple wireless networks with the same SSID, select the ones with the WLAN MAC
addresses of the CPE2 and CPE3, which are C8:3A:35:15:86:8C and C8:3A:35:01:8C:C9 in this example.
