This can indicate whether there’s an active Ethernet connection on the corresponding port.
Wireless Info
Working Mode --- Display the operating mode of the device.
SSID --- Display the WiFi name (SSID).
Security Mode --- Display the wireless security method being used on the device.
Channel/Bandwidth --- Display the channel number and corresponding operating frequency.
Wireless client --- Indicate the number of connected wireless clients.
Remote AP MAC --- In AP/Router mode, it displays as Not Associated. In Station/Universal
Repeater/WISP/P2MP/Repeater mode, it displays the MAC address of the remote AP the
device is associated with.
Signal Strength --- Display the received wireless signal level.
Noise floor --- Display the current value (in dBm) of the environmental noise the receiver
hears on the operating frequency.
TX/RX Link --- Display the number of independent spatial data flow the device is
transmitting (TX) and receiving (RX).
TX/RX Rate --- (Available in Station mode only.) Display the current 802.11 data
transmission (TX) and data reception (RX) rates.
Statistics
Throughput --- Display the current date traffic on the LAN and WLAN. The chart scale and
throughput dimension change dynamically depending on the mean throughput value. The
statistics are updated automatically.
Clients --- (Available in AP and Router mode) Display clients that are connected to the
device.
AP Information --- (Available in Station/WISP/Universal Repeater/P2MP/Repeater mode.)
Display the connection statistics of the AP associated with the device.
Interface --- Display MAC address, IP address, and traffic information of the device’s
interfaces.
ARP Table --- List all the entries of the Address Resolution Protocol (ARP) table currently
recorded on the device.
Routing Table --- Display all the entries in the system’s routing table.
