Tenda i27 Quick Installation Guide

- 14 -
Q3. What should I do if AP wireless bridge failed?
A3. Try the following solutions:
Verify that the Key for the wireless network of the uplink
device (AP1 in this guide) is correct.
Check whether the signal of the wireless network of the
uplink device (AP1 in this guide) is too weak. If so, move the
local AP (AP2 in this guide) closer to the uplink device.
Q4. How to restore the AP to factory settings?
A4. Try the following solutions:
When AP is not busy, hold down the RESET button with a
needle-like object for about 8 seconds and release it when
the LED indicator turns off. When the LED indicator is
blinking white, AP is reset successfully.
Q5. I forgot the username and password when accessing
the management web UI of the AP. What should I do?
A5. Try to log in with the default user name and password (admin).
If it fails, restore the AP to factory settings (refer to Q4) and
then use the default user name and password to log in again.

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
