Tenda O1 User Manual

25
Name
Description
Working modes
It specifies the working mode of this device.
AP mode: In this mode, the device creates a wireless network based on the current
wired network.
SSID
It specifies the wireless network name of this device.
Channel
It specifies the operating channel of this device. Select a less used channel in the
ambient environment to reduce interference.
Auto: It indicates that the device automatically adjusts its operating channel according
to the ambient environment.
Security Mode
It specifies the security mode of the wireless network, including: None, WPA-PSK,
WPA2-PSK, and Mixed WPA/WPA2-PSK.
Clicking the hyperlink navigates you to the elaborated description of the
corresponding security mode.
Encryption Algorithm
It specifies the encryption method of the wireless network.

AES: It indicates the Advanced Encryption Standard.

TKIP: It indicates the Temporal Key Integrity Protocol. If TKIP is used, the maximum
wireless throughput of the device is limited to 54 Mbps.

TKIP&AES: It indicates that both TKIP and AES encryption algorithms are supported.
Wireless clients can connect to the wireless network corresponding to the selected
SSID using TKIP or AES.
Key
It specifies the WiFi password of the wireless network.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
