Tenda O1 User Manual

55
5. Click Save, and wait until the device reboots to activate the settings.
Step 2 Perform Step 1 above to set CPE3 to Repeater mode, and bridge to CPE1.
Step 3 Set CPE1 to Repeater mode and bridge to CPE2 and CPE3.
1. Start a web browser on the computer connected to CPE1, and visit 192.168.2.1.
2. Choose Quick Setup to enter the configuration page.
3. Select Repeater mode, and click Next.
4. Select SSIDs of CPE2 and CPE3, and click Next at the bottom of the page.
If there are multiple wireless networks with the same SSID, select the ones with the WLAN MAC
addresses of the CPE2 and CPE3, which are C8:3A:35:15:86:8C and C8:3A:35:01:8C:C9 in this example.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
